Enterprise 1U Cloud
Rack Server 4 x 3.5-inch Drive Bays Dual Intel Xeon E5-2600V4 Processors up to 1.54TB DDR4 Memory. Optional -48v DC Power
Server
Chassis: Premium Intel Rack Mount Server1UForm Factor Dimensions: 27.95"(709.93mm) Depth x 1.7" (43.2mm) Height x 17.25" (439mm) Wide Processor: Socket R, Single or Dual E5-2600V4 up to 22-Cores per Intel Xeon Processor Memory: 24 DIMM slots support up to 1536GB DDR4/2133 E.C.C. Registered Storage:4 x Hot-Pluggable Drive Bays, supports 3.5-inch and 2.5-inch SSD, SATA and SAS Drives.
Integrated SW SATA RAID Controller. Two configurable RAID Modes via BIOS;
Intel RSTe SW RAID supports 0, 1, 10, 5
Intel Server RAID Technology II (LSI) supports 0, 1, 10
USB Ports: 2 x USB-3.0 Front Panel and 3 x USB-3.0 Ports on Rear Panel AC Power: Single 750-watt H/S Platinum Effiency with option for Dual (2) 750-Watt
Hot-Pluggable Redundant Platinum Efficiency Power Supplies DC Power:Optional Single or Dual Redundant -48v 750-Watt Hot-Pluggable 80 Gold Efficiency Power Supplies Networking:Dual (2) integrated Intel i350 1GbE (10/100/1000) Server Controllers PCI Expansion: 2 x PCI-Express 3.0 x24 Slots Video: Front and Rear Panel VGA Connectors, Integrated 2D Controller with 16MB DDR3 Memory Serial Port: RJ45 on Rear Panel Technology Features:
• Intel Remote Management Module
• Intel On-Demand Redundant Power
• Intel Advanced Management Technology
• Intel Server Customization Technology
• Intel Build Assurance Technology
• Intel Efficient Power Technology
• Intel Quiet Thermal Technology
• Intel Virtualization Technology for Directed I/O (VT-d)
• Intel Rapid Storage Technology enterprise Remote Management: Included Remote Lights-Out Management. Redirected KVM (Keyboard, Video, Mouse) with Dedicated 10/100 Network Connector on Rear Panel Suggested Applications:Virtualization,High Performance Computing, Database Hosting
Enterprise 1U Cloud
Rack Server 8 x 2.5-inch Drive Bays Dual Intel Xeon E5-2600V4 Processors up to 1.54TB DDR4 Memory with Optional -48v DC Power
Server
Chassis: Premium Rack Mount Server1UForm Factor Dimensions: 30.25"(769.93mm) Depth x 1.7" (43.2mm) Height x 17.25" (439mm) Wide Processor: Socket R, Single or Dual E5-2600V4 up to 22-Cores per Intel Xeon Processor Memory: 24 DIMM slots support up to 1536GB DDR4/2133 E.C.C. Registered Storage:8 x Hot-Pluggable Drive Bays, supports 2.5-inch SSD, SATA and SAS Drives.
Integrated SW SATA RAID Controller. Two configurable RAID Modes via BIOS;
Intel RSTe SW RAID supports 0, 1, 10, 5
Intel Server RAID Technology II (LSI) supports 0, 1, 10
USB Ports: 2 x USB-3.0 Front Panel and 3 x USB-3.0 Ports on Rear Panel AC Power:Single (1) 750-Watt
Hot-Pluggable Redundant Platinum Efficiency Power Supply with option for Dual Redundant Power Supplies DC Power:Optional Single or Dual Redundant -48v 750-Watt Hot-Pluggable 80 Gold Efficiency Power Supplies Networking:Dual (2) integrated Intel x540 10GbE (10/100/1000/10000) Server Controllers PCI Expansion: 2 x PCI-Express 3.0 x24 Slots Video: Front and Rear Panel VGA Connectors, Integrated 2D Controller with 16MB DDR3 Memory Serial Port: RJ45 on Rear Panel Technology Features:
• Intel Remote Management Module
• Intel On-Demand Redundant Power
• Intel Advanced Management Technology
• Intel Server Customization Technology
• Intel Build Assurance Technology
• Intel Efficient Power Technology
• Intel Quiet Thermal Technology
• Intel Virtualization Technology for Directed I/O (VT-d)
• Intel Rapid Storage Technology enterprise Remote Management: Included Remote Lights-Out Management. Redirected KVM (Keyboard, Video, Mouse) with Dedicated 10/100 Network Connector on Rear Panel Suggested Applications:Virtualization,High Performance Computing, Database Hosting
1U Ruggedized Rack Server
NEBS Level 3 Certified with -48 Volt D.C. Power Option
Server
Chassis:1U Rack Server 20-inch Short Depth
Ruggedized NEBS Level-3 / ETSI Certified (with DC Power Option):
NEBS GR-63-CORE, Issue 3 - Physical Protection
NEBS GR-1089-CORE, Issue 4 - Electromagnetic Compatibility and Electrical Safety
ETSI Standards Compliance (DC Input Only) Environmental: Extreme Heat, Humidity, Altitude,
Zone 4 Earthquake Shock and Flame-resistant. Processor: One or Two Low Voltage Quad/Six or Eight-Core Intel Xeon E5-2400 Series Chipset: Intel® C602(-A) Chipset Memory: Up to 128GB DDR3/667Mhz Storage: 4 x Hot-Pluggable SAS/SSD Hard Drive Bays Power: Redundant AC or 48
Volt DC Networking: Four integrated Intel I350 10/100/1000
Server Network Controllers PCI Expansion: 1 PCIe Gen3 x16 Riser Slot Video: Integrated Server Engines LLC Pilot
II Controller with 16MB DDR3 Memory Remote Management:Web
Based, OS Independent, Console Redirection, KVM, IPMI Suggested Applications: Virtualization,
Intrusion Detection System, SIP Server, VoIP Server, Video Rendering, Database Hosting, Email Spam
Processing, SMTP Server, Java Applications, Web Farms, HPC, Telco Server
2U 20-Inch Depth NEBS Level-3/ETSI Compliant
Rack Server Intel Scalable Xeon Processors with -48 Volt Redundant Power Option
Chassis:
Designed to meet NEBS-3/ETSI certification, the NEBS Level-3/ETSI Compliant2u 20-Inch Depth
Rack Server:
NEBS GR-63-CORE, Issue 3 - Physical Protection
NEBS GR-1089-CORE, Issue 4 - Electromagnetic Compatibility and Electrical Safety
ETSI Standards Compliance (DC Power Input Only) Environmental: Extreme heat, humidity, altitude,
zone 4 earthquake shock, and is flame-resistant. Processor: One or Two Dual-socket 1st/2nd Generation Intel® Xeon® Scalable processors up to 28-Cores/processor Memory: 16 DIMM slots supporting up to 2048GB (2TB) DDR4/2933Mhz Storage: Up to 6 Hot-Pluggable SAS, SATA or SSD
Drives Networking: Two (2) x Intel 10GbE NICS Server Network Controllers
Additional I/O: Up to 7 PCI Slots
Power Supply:Redundant AC or -48
Volt DC Remote Management: IPMI-2.0 with options for
Web Based Remote Management and Console with KVM. OS Independant. SNMP v2c and v3 compliant Extended Life Cycle: Longer product availability,
warranty and spares support for excellent investment protection Suggested Applications: Virtualization,
VoIP, Web Server, Email Server, Specialized Networking and Telecom Applications, Intrusion Detection System, Video Rendering, Database Hosting, Email Spam Processing, SMTP Server, Java Applications, Web Farms, HPC
D.C. Powered Servers | 1U -48V Rack Server | 2U -48V Rack Server
D.C. Powered (-48VDC) Servaris Rack Servers are customized to your requirements and built exclusively with Premium Quality Components. The customization and quality craftsmanship provides you with the hardware backbone to run sophisticated back end software with the degree of reliability that is unsurpassed.
