Servaris Premium 2U Rack
Servers are designed for high efficiency data delivery and provide you
with the latest Virtualization Server Technology. High Efficiency Power
Supplies and Intel 5600 Six-Core and Quad-Core Westmere Xeon Processors reduce IT costs. Built-in
Remote Lights-out Management provides you with ease of managing your
2U Rack Servers.
|
2U
Rack Servers built with Intel 5600 Six-Core and Quad-Core Xeon Processors |
More Information
|
2U Rack Server
Integrated SATA-300 RAID Dual Intel Six-Core 5600 or 5500 Quad-Core Processors
|
Server
Chassis: Premium 2U Rack Server
Processor: One or Two Six-Core
5600 or Quad-Core Nehalem Intel 5500 Xeon
Memory: Up to 192GB
Registered DDR3
Internal Storage: 6 Hot-Pluggable Drive Bays.
SATA RAID (0,1,10 with integrated controller)
Power: Hot-Pluggable Redundant High-Efficiency
750-Watt Power Supplies
Networking: Two Intel 82575EB PRO/1000 Server
Network Controllers
PCI Expansion: up to 5 PCI Expansion Cards
(PCIe/PCIx) and Optional I/O Modules (Quad Port 82576 NICs, Dual Port
10GbE, QDR speed InfiniBand)
Video: On-board Server Engines LLC Pilot
II Controller
Virtualization: Intel® Virtualization Technology2
Remote Management: Web
Based, OS Independent, KVM and Console Redirection, IPMI
Suggested Applications: Virtualization,
Intrusion Detection Systems, Video Rendering, Database Hosting, Email
Spam Processing, File Server
|
|
More Information
|
2U Rack Server
Integrated Hardware SAS RAID Back-End Infrastructure Database Server |
Server
Chassis: Premium Advanced 2U Server
Processor: One or Two Six-Core 5600 or
Quad-Core 5500 Nehalem Intel Xeon
Memory: Up to 192GB
Registered DDR3
Storage: 8 Hot-Pluggable
2.5-inch SAS and/or SATA Hard Drives Full Featured Hardware RAID
and 72 Hour Backup Battery.
Power: Single Hot-Pluggable 750-Watt upgradeable
to Dual Redundant
Networking: Two Intel 82575EB PRO/1000 Server
Network Controllers
PCI Expansion: 5 PCI-E Expansion Card Slots
(3 Full Height and 2 Low-Profile) and Optional I/O Modules (Quad Port
82576 NICs, Dual Port 10GbE, QDR speed InfiniBand)
Video: On-board Server Engines LLC Pilot
II Controller
Intel® Virtualization Technology2: Run multiple
Operating Systems and Applications on a single Server
Remote Management: Web
Based, OS Independent, Console Redirection, IPMI
Suggested Applications: Virtualization,
Back-End Database Warehousing, Number Crunching, Intrusion Detection Systems,
Video Rendering, Web Farm, Web Server, Database Server |
|
| |
2U Rack Servers Built on Intel 5400 Quad-Core Xeon Technology |
More Information
|
2U Rack Server
Integrated SATA-300 RAID Back-End Infrastructure Database Server |
Server
Chassis: Premium Advanced 2U Server
Processor: One or Two Quad-Core 5400 Intel
Xeon
Memory: up to 64GB DDR2/667
Storage: 6 Hot-Pluggable
Hard Drive Bays with Integrated SATA-300 RAID.
Power: Single Hot-Pluggable 750-Watt upgradeable
to Dual Redundant
Networking: Two Intel 82563EB PRO/1000 Server
Network Controllers
PCI Expansion: up to 5 PCI Expansion Cards
(PCIe/PCIx) and Optional I/O Modules (Quad Port 82576 NICs, Dual Port
10GbE, QDR speed InfiniBand)
Video: On-board Server Engines LLC Pilot
II Controller
Intel® Virtualization Technology2: Run multiple
Operating Systems and Applications on a single Server
Remote Management: Web
Based, OS Independent, Console Redirection, IPMI
Suggested Applications: Virtualization,
Back-End Database Warehousing, Number Crunching, Intrusion Detection Systems,
Video Rendering, Web Farm, Web Server, Database Server |
|
2U NEBS-3 Certified Rack Servers Built on Intel 5600 Six-Core and Quad-Core Xeon Technology |
More Information
|
2U NEBS Level-3 ETSI Certified
Rack Server with -48 Volt Redundant Power Option |
Chassis:
NEBS Level-3 ETSI Certified 2U 20-Inch Depth
Rack Server
Environmental: Extreme heat, humidity, altitude,
zone 4 earthquake shock, and is flame-resistant.
Processor: One or Two Six-Core
or Quad-Core Intel 5600 Westmere Xeon , 1333Mhz
Front Side Bus
Memory: Up to 96GB DDR3/1333
Storage: Up to 6 Hot-Pluggable SAS or SATAHard
Drives
Networking: Two Intel PRO/1000 Server Controllers
Power Supply: Redundant AC or -48
Volt DC
Remote Management: IPMI-2 with options for
Web Based Remote Management. OS Independant.
Extended Life Cycle: Longer product availability,
warranty and spares support for excellent investment protection
Suggested Applications: Virtualization,
VoIP, Specialized Networking and Telecom Applications
|
|
NEBS-3 ETSI Certifed 2U Rack Servers Performance Built on Intel 5400 Quad-Core Xeon Technology |
More Information
|
2U Rack Server NEBS Level
3 ETSI Certified IP Networking VoIP and Digital Services |
Server
Chassis: Advanced Ruggedized 2U Rack Server
Processor: One or Two Quad-Core Intel 5400
Xeon
Memory: Up to 32GB DDR2/667
Storage: Up to 6 Hot-Pluggable 2.5"
SAS Hard Drives
Networking: Two Intel PRO/1000 Server Controllers
and up to 8 GBe Front Port Ethernet and/or Optical
NICS
Power Supply: Standard AC or -48
Volt D.C.
Remote Management: IPMI, FreeBSD, Windows
and Linux
Extended Life Cycle: Longer product availability
and spares support for excellent investment protection.
Suggested Applications: Specialized
Networking Applications, Rugged Environments, Virtualization |
|
