12-Bay 2U RAID Storage Subsystem
8GB Fibre to SAS/SATA. Expandable to 60 Hard Drives |
RAID
Chassis: Premium 2U 12-Bay Rack Chassis
Storage: Up to 12 SAS and/or SATA-300
Hard Drives
Memory: 2GB DDR2/667Mhz
RAID Controller: Single High-Performance
ASIC 667 Infortrend
Host Adapters: 2 x 8GB Fibre Host
Ports
Expansion : 1 SAS Wide Expansion Port. Connect
up to 6 iStor 12-Bay JBOD Expansion Chassis. 84 Hard Drives Maximum
Interfaces: Two DB9 Serial and One 10/100BaseT
Ethernet Ports
Power: Redundant Hot-Pluggable Power Supplies
Remote Management: WEB, GUI, Serial and SNMP |
More Information
 |
|
Subsystem: 2U Rackmount
Storage: Up to 12 SATA II Hard Drives
RAID Controller: Single High-Performance Infortrend RAID Controller
Host Adapters: 2 x SAS Wide Ports
Interfaces: Two DB9 Serial and One 10/100BaseT Ethernet Ports
Cooling: Redundant Hot-Pluggable Fans
Power: Redundant Hot-Pluggable Power Supplies
Remote Management: WEB, Serial, GUI and SNMP
Warranty: 3 Year Warranty. Optional 3 Year On-Site Warranty and Maintenance.
 More Information
|
Subsystem: 3U Rackmount
Storage: Up to 16 SATA II Hard Drives
RAID Controller: Single High-Performance Infortrend RAID Controller
Host Adapters: 4 x SAS Wide Ports
Interfaces: Two DB9 Serial and One 10/100BaseT Ethernet Ports
Cooling: Redundant Hot-Pluggable Fans
Power: Redundant Hot-Pluggable Power Supplies
Remote Management: WEB, GUI, Serial and SNMP
Warranty: 3 Year Warranty. Optional 3 Year On-Site Warranty
More Information
|
|
Subsystem: 4U Rackmount
Storage: Up to 24 SATA II Hard Drives
JBOD Expansion: Up to 4 x iStor 12-Bay JBOD Systems (88 Drives Total)
RAID Controller: Single High-Performance Infortrend
Host Adapters: Four SAS Host Ports
Interfaces: Two DB9 Serial and One 10/100BaseT Ethernet Ports
Cooling: Redundant Hot-Pluggable Fans
Power: Redundant Hot-Pluggable Power Supplies
Remote Management: WEB, GUI, Serial and SNMP
Warranty: 3 Year Limited Warranty. 3 Year Optional On-Site Warranty
More
Information
|
Subsystem: 4U Rackmount
Storage: Up to 24 SATA II Hard Drives
JBOD Expansion: Up to 2 x iStor 16-Bay JBOD Systems (56 Drives Total)
RAID Controller: Dual Redundant
High-Performance Infortrend
Host Adapters: Eight SAS Host Ports
Interfaces: Two DB9 Serial and One 10/100BaseT Ethernet Ports
Cooling: Redundant Hot-Pluggable Fans
Power: Redundant Hot-Pluggable Power Supplies
Remote Management: WEB, GUI, Serial and SNMP
Warranty: 3 Year Limited Warranty. 3 Year Optional On-Site Warranty
More
Information
|
|
